HIGHLIGHTS
BRACKETS
CEILING DETAIL
OPTIONAL UPGRADES
STAIN
CEDAR TONE
BROWN
RED
+$399
Stain sold separately (choose color in cart).
Western Red Cedar
The Cadillac of wood species in our opinion. Naturally beautiful, with rich, tonal properties, red cedar is ideal for holding a wide range of beautiful finishes. Western Red Cedar is more flame-resistant than most woods, weathers seasonality, and comes naturally infused with exceptional physical properties. This is the real deal, folks!
SPECS
- Nominal Size: 12' x 12'
- Overall Size (W x D x H): 12' x 12' x 17'2"
- Space between each Post (Front): 8'4"
- Space between each Post (Side): 8'4"
- Decking: 1" x 6" Pine Tongue & Groove
- Roof Material: Asphalt Shingles - Limited lifetime warranty
- Construction: North American Timber - resistant to rot, decay & insects
- Hardware: Finished with exterior grade powder coating for the ultimate protection
- Wind Rating: 130 M.P.H.
SPECS
- Nominal Size: 14' x 14'
- Overall Size (W x D x H): 14 x 14' x 17'10"
- Space between each Post (Front): 10'4"
- Space between each Post (Side): 10'4"
- Decking: 1" x 6" Pine Tongue & Groove
- Roof Material: Asphalt Shingles - Limited lifetime warranty
- Construction: North American Timber - resistant to rot, decay & insects
- Hardware: Finished with exterior grade powder coating for the ultimate protection
- Wind Rating: 130 M.P.H.
SPECS
- Nominal Size: 14' x 18'
- Overall Size (W x D x H): 14 x 18' x 17'10"
- Space between each Post (Front): 10'4"
- Space between each Post (Side): 14'4"
- Decking: 1" x 6" Pine Tongue & Groove
- Roof Material: Asphalt Shingles - Limited lifetime warranty
- Construction: North American Timber - resistant to rot, decay & insects
- Hardware: Finished with exterior grade powder coating for the ultimate protection
- Wind Rating: 130 M.P.H.
SPECS
- Nominal Size: 14' x 22'
- Overall Size (W x D x H): 14' x 22' x 17'10"
- Space between each Post (Front): 10'4"
- Space between each Post (Side): 18'4"
- Decking: 1" x 6" Pine Tongue & Groove
- Roof Material: Asphalt Shingles - Limited lifetime warranty
- Construction: North American Timber - resistant to rot, decay & insects
- Hardware: Finished with exterior grade powder coating for the ultimate protection
- Wind Rating: 130 M.P.H.
SPECS
- Nominal Size: 18' x 18'
- Overall Size (W x D x H): 18' x 18' x 19'2"
- Space between each Post (Front): 14'4"
- Space between each Post (Side): 14'4"
- Decking: 1" x 6" Pine Tongue & Groove
- Roof Material: Asphalt Shingles - Limited lifetime warranty
- Construction: North American Timber - resistant to rot, decay & insects
- Hardware: Finished with exterior grade powder coating for the ultimate protection
- Wind Rating: 130 M.P.H.
SPECS
- Nominal Size: 22' x 22'
- Overall Size (W x D x H): 22' x 22' x 20'6"
- Space between each Post (Front): 18'4"
- Space between each Post (Side): 18'4"
- Decking: 1" x 6" Pine Tongue & Groove
- Roof Material: Asphalt Shingles - Limited lifetime warranty
- Construction: North American Timber - resistant to rot, decay & insects
- Hardware: Finished with exterior grade powder coating for the ultimate protection
- Wind Rating: 130 M.P.H.
| 12'x12' | 14'x14' | 14'x18' | 14'x22' | 18'x18' | 22'x22' | |
|---|---|---|---|---|---|---|
| A | 12' | 14' | 14' | 14' | 18' | 22' |
| B | 12' | 14' | 18' | 22' | 18' | 22' |
| C | 9'8" | 11'8" | 11'8" | 11'8" | 15'8" | 19'8" |
| D | 9'8" | 11'8" | 15'8" | 19'8" | 15'8" | 19'8" |
| E | 13'10" | 14'6" | 14'6" | 14'6" | 15'10" | 17'2" |
| AGable depthB Depth at ridgeC Post footprint frontD Post footprint sideEMaximum height | ||||||
TRUE
Customization
We believe in building things better. If one of our models just doesn’t quite make you happy, then let’s help you design one that does. Let’s get started!
